SKU:59669398
A Float switch is a device used to sense the level of liquid within a tank. The switch may actuate a pump, an indicator, an alarm, or other device. It can be easily Converted from normally open to normally close by inverting the Float. Note: because the current that the switch can carry is much little(0.5a), you must use a relay or Contactor when it is connected by a load, relay and Contactor are not included here.
Product name float switch; max contact Rating max contact Rating; 10W 10W; max switching Voltage 100V DC
Max switching current 0.5A; max breakdown Voltage 220V DC; max carry current 1.0A; max contact resistance 100mî
Temperature Rating -10 ~ +60 â°c / 85 â°c; float ball material PP; float body material PP; float ball size(approx.) 25 x 26 mm / 1" x 1.1"(L*d)
Thread dia(approx.) 9 mm / 0.35"; nut dia(approx.) 14 mm / 0.55"; bottom clip dia(approx.) 20 mm / 0.8"; body total Length 22 cm / 8.6"
Cable Length 35 cm / 13.8 inch
